Control Levers

RPCL-01

RPCL-02

RPCL-03

RPCL-01

Hand Operated Rack & pinion Type Control Lever

 Light duty Rack & Pinion Type Control Lever.
 Provision of Mechanical Detent is possible.
 Maximum Travel: 72 mm.
 Die Cast Aluminium Alloy Construction with steel rack & pinion.
 Surface Finish : Powder coated ( Black)

Applications:

•   Throttle Control.
•   Hydraulic Motor/ Pump Control.

RPCL-02

Hand Operated Double Rack & pinion Control Lever

Medium/ Heavy duty Twin Rack & Pinion Type Control Lever.
Provision of Mechanical Detents for both levers.
Maximum Travel: 100 mm.
Die Cast Aluminium Alloy Construction.
Finish: Powder Coated ( Black).

Applications:

•  Throttle Control in Transit Mixers.
•  Hydraulic Motor/ Pump Control for Transit Mixers.

RPCL-01

Hand Operated Single Rack & pinion Control Lever

Medium/ Heavy duty Single Rack & Pinion Type Control Lever.
Provision of Mechanical Detent.
Maximum Travel: 100 mm.
Die Cast Aluminium Alloy Construction.
Finish: Powder Coated ( Black).

Applications:

•  Forward / Reverse direction control of engine driven winch.
•  Hydraulic Motor/ Pump Control for Transit Mixers.
